With its widened 23mm UD carbon rim, the Cosmic SL 45 is the most versatile of Mavic's carbon wheels, with improved comfort and performance.
Improved aerodynamics - Less drag, more watts thanks to its 45mm rim profile and flat spokes developed by our aero experts and wind tunnel tested.
Even more responsive - With INFINITY hubs, power transfer is ultra-efficient and the wheel is even more responsive.
Unrivalled versatility - The lightness of its 23mm rim and its spoking make the Cosmic SL 45 Disc the most versatile Mavic road wheel ever designed.
| Specification |
- Weight
- Pair : 1555 g
- Front : 720 g
- Rear : 835 g
- Rims
- Material: 100% Unidirectional carbon fiber
- Height: 45 mm
- Internal width: 23 mm
- Drilling: traditional (front/rear 24 holes)
- Braking: disc
- ETRTO size: 622x23TC
- Tire: UST Tubeless Ready - Use with Mavic Tubeless Tape
- Spokes
- Material: steel
- Shape: straight, extra-flat, constricted, antirot (front and rear)
- Nipples: steel, ABS, black
- Lacing: crossed 2 (front and rear)
- Hubs
- Body material: aluminium
- Body design: INFINITY
- Disc standard: Center Lock® only
- Axle material: aluminum
- Axle size: front 12x100 / rear 12x142 - Convertible to quick release with adapters (not included)
- Freewheel: Shimano HG road
- Bearing technology: QRM automatic setting - sealed cartridge
- Compatibility
- Freewheel body: convertible SRAM XD road (kit V2580101 sold separately)
- Freewheel body: convertible SHIMANO HG light road (kit V3850101 sold separately)
- Freewheel body: convertible SHIMANO MS (kit V3990101 sold separately)
- Freewheel body: convertible CAMPAGNOLO ED (kit V3440101 sold separately)
- Freewheel body: convertible CAMPAGNOLO N3W (kit V4270101 sold separately)
- Front axle adapters: 12x100 convertible to 9x100 (kit V2680301 sold separately)
- Rear axle adapters: 12x142 convertible to 9x135 (kit V2510801 sold separately)
- Rear axle adapters: 12x142 convertible to 12x135 (kit V2510901 sold separately)
- Intended use
- Minimum tyre size: width 28mm - pressure max. 5.5Bar/80PSI
- Maximum tyre size: width 64mm - pressure max. 3.25Bar/47PSI
- ASTM category 2 : road and offroad with jumps less than 15cm
- Maximum weight supported by the wheels: must not exceed 120 kg (bike weight included)
|
| in the box |
| User guide Rim tape mounted on wheel UST valve not mounted on wheel Multifonction adjustment wrench with the rear wheel |
